Minimize the risk of premature battery and charging failure, reduce total cost of ownership, and maximize machine uptime with our charging solutions.
Combining a battery charger, DC-DC converter, and EVSE interface into one unit helps minimize cabling, reduce component count, and free up valuable installation space.
Support for SAE J1939, CANopen, and UDS protocols enables seamless communication with vehicle control units and battery management systems.
Available in 125V, 500V, and 1000V models, the ZQ7200 supports 100V, 400V, and 800V battery systems used in modern electric vehicles and mobile machinery.
The ZQ7200 is available in multiple voltage configurations to support a wide range of electric vehicle and mobile machinery applications. Explore specifications, integration options, and charging capabilities to find the right solution for your battery system.
More Details
| 125 V Model | 500 V Model | 1000 V Model | |
|---|---|---|---|
| Max DC Output Power | 7200 W | 7200 W | 7200 W |
| Output Voltage Range | 80-125 VDC | 250-500 VDC | 500-1000 VDC |
| DC/DC Converter Nominal Power Output (Max) | 1000 W | 1000 W | 1000 W |
| AC Input Voltage Range | 90-300 V (100 – 277 Vnominal) | 90-300 V (100 – 277 Vnominal) | 90-300 V (100 – 277 Vnominal) |
| Battery Type | Lithium Only | Lithium Only | Lithium Only |
| All Models | |
|---|---|
| Dimensions | 432 x 249 x 85 mm (17 x 9.8 x 3.3” ) |
| Weight | 9.8 kgs (21.6 lbs) |
| Cooling | Liquid (50:50% Glycol/Water) |
| IP Protection | IP66/IP67 |
| All Models | |
|---|---|
| Efficiency | ≥94.6% |
| Safety | UL 1564, CSA 22.2 No.107.2, EN IEC 62477-1 |
| Emissions | FCC Part 15 / ISED ICES-002, Class A EN IEC 61000-6-4, EN IEC 61000-3-11/-12 |
| Immunity | EN 61000-6-2 |
Build an electric drive product with better flexibility and longevity with our battery charging solutions, all developed with your needs in mind.
Consolidates battery charging, auxiliary power conversion, and charging station communication into a single compact solution, helping OEMs reduce component count, simplify vehicle architecture, and optimize installation space.
Supports major global charging standards, enabling OEMs to deploy vehicles across multiple regions while reducing complexity and streamlining charging infrastructure compatibility.
Provides advanced control and monitoring capabilities, allowing for greater system flexibility, enhanced diagnostics, and seamless integration with modern electric vehicle platforms.
Designed with cybersecurity in mind, helping protect charger functionality, software integrity, and vehicle systems from unauthorized access.
Delivers high charging performance in a compact footprint, helping OEMs maximize available space without compromising vehicle capabilities.
Supports next-generation battery architectures, giving OEMs the flexibility to design vehicles around 100V, 400V, and 800V battery systems while preparing for future electrification requirements.
Benefit from over 23 years of engineering innovation, quality and product performance with Delta-Q’s battery chargers, the solution of choice for tier one OEMs.
Mobile robots are gaining popularity in various industries to solve labor shortages and worker safety concerns. Universally electric, robotics equipment is powered primarily by lithium batteries, requiring the sophisticated and cost-effective solutions Delta-Q specializes in.
Learn More
From harsh settings to long hours, the construction industry requires high demands from its machinery. Delta-Q’s chargers provide safe and reliable power to lithium battery systems for all construction environments and use cases.
Learn More
Agricultural environments are often characterized by long duty cycles and challenging weather patterns, which require both power and durability from their charging equipment. Delta-Q’s charging solutions are designed for these needs.
Learn More
Find the perfect battery and charger combination to provide your products with best-in-class performance, prolonged battery life, and maximum up-time with Charged by Delta-Q.
Can’t find the right charger and battery combination? Contact our team for a free consultation!
